I/O Wiring

pompy wtryskowe cheap huarache shoes bombas inyeccion cheap jordans cheap air max cheap sneaker cheap nfl jerseys cheap air jordans cheap jordan shoes cheap wholesale jordans

One of the many advantages to using a PLC/PAC is the simplicity of the I/O wiring.

I/O devices are wired to I/O points on a fixed I/O unit and to I/O modules in a modular unit. Input devices such as switches, pushbuttons and sensors are wired to input module points and output devices such as indicator lights, solenoids and motor starter coils are wired to output module points.

Note: For this tutorial we will be referring to modular PLC/PAC's.

I/O modules can accept ACV, DCV or a combination of ACV and DCV. Most modern automation systems use DCV I/O, therefore we will focus on DCV.

DC voltage has a polarity. We already know that current flow is from negative to positive. This current flow is also referred to as electron flow and is also the current that is measured when making measurements with a meter.

There is also another current flow. This current flow is called 'conventional current' and is the current flow that solid state physis use. This current flows from positive to negative. When electrons flow from one atom to another they leave a hole behind on the atom that they leave. If you could watch the electrons moving from atom to atom, the electrons would be moving in one direction (negive to positive) and the holes would look like they are moving in the opposite direction (positive to negative).

DCV I/O module polarity is referenced using the terms sink and source. The terms are derived from conventional current flow, but we will explain sink and source in terms of electron flow.

Why should we care what direction current is flowing? Mechanical switches, indicator lamps and solenoids don't care what polarity the current is flowing. But sensors such as photoelectric, inductive and capacitive proximity sensors are also wired to PLC/PAC I/O modules. These sensors are solid state, using diodes and transistors in their internal workings. These devices require current to be flowing in the right direction.

Definition: Sink/Source
Click the terms for details and wiring diagram examples).

Sink Connections
A sink I/O device or I/O module will always have a connection to the negative side of the DC power supply. The negative side of the DC power supply is referred to by any one of or either of the terms: ground, common, DC common, return, DC return, etc. All these terms refer to the same electrical point; the negative side of the DC power power supply.

Sink is designated NPN.

Source Connections
A source I/O device or I/O module will always have a connection to the positive side of DC power supply. The positive side of the DC power supply is referred to as VDC+, positive, etc.

Source is designated PNP.
